Vina- Hydraulic Equipment Joint Stock Company (VHE) completed the order of processing 400 Micro Hose DN2 5/64" threads with a pressure of 630 bar. These types of test hoses are processed with the following requirements:
+ Hydraulic Test Point Hose, DN2, 2 ends fitted with test point M16x2, length 2000mm, pressure 630bar, code SMA3-2000, Parker
+ Hydraulic Test Point Hose, DN2, 630bar, 1 end fitted with a test point M16x2mm, 1 meter connector G1/4 inch, length 4 m
+ Hydraulic Test Point Hose, DN2, 630bar, 2 ends fitted with M16x2mm test point, length 4 m
+ Hydraulic Test Point Hose, DN2, 630bar, 1 end fitted with M16x2mm test point, 1 end fitted with G1/2 inch thread meter, length 4 m
About the technical information Hydraulic Micro Test Point Hose
- The outer layer is made from black polyurethane, anti-adhesion
- The second layer is braided with Aramid fiber to enhance durability and provide better resistance.
- The innermost layer is made of polyester-elastomer material (thermoplastic elastomer, thermoplastic rubber)
- Operating pressure: 630 bar (9100 Psi)
- Explosion pressure: 1900 bar (27300 Psi)
- Bending radius: 20 mm
- Weight: 0.02kg/m
A test hose pressure line is the necessary equipment to follow the operation process of the system. Often used in small hydraulic circuit systems, checking oil pressure on the system, attaching to a meter to test pressure, taking liquid samples,...
VHE is currently a wholesale and retail agent for genuine Micro Disca hydraulic hoses with full sizes and provides service of pressing the ends of Micro Hose hoses of all kinds with a team of professional processing technicians and many years of experience. Contact VHE immediately to get a good quote!
